This adapter supports converting SD, SDHC, SDXC, SDIO, iSDIO, miniSD (with adapter), microSD (with adapter), microSDHC/SDXC (with adapter), MMC, RS-MMC (with adapter), MMC Plus, and MMC Mobile (with Adapter) to Type II CardBus PC Card. A Push-Push socket is equipped for easy insertion/extraction of supported cards. Also compliant with SDIO specification, which allows you to use SDIO/iSDIO card with all kinds of applications on your computer.
Compliant with 16/32-bit(CardBus) Type II PC Card interface (JEIDA 4.2).
Maximum frequency reaches 33MHz.
Compliant with SD Memory Card Specification 2.0.
Supports SDHC / High Speed SD Clock (50MHz)
Compliant with SDIO (required additional driver for respective SDIO card)
Supports iSDIO( Eye-Fi card, Wireless LAN SD, Wi-Fi SD )
Compliant with SD Host Controller Standard Specification 1.0.
Compliant with MultiMediaCard Specification 4.1.
Supports MMC Plus and MMC Mobile (with adapter.).
Push-Push card slot for easy insertion/extraction of card.
Low power consumption, 3.3V single power operation.
Software Suspend mode compliant with ACPI.
Supports Hardware Suspend.
Supporting file System: FAT(FAT12/FAt16)/FAT32/exFAT(FAT64)/NTFS
Device string in OS: SD to ATA/PCMCIA adapter device(no specific VID/PID, generic driver supported by OS)
Input Socket SD / SDHC /SDXC (SD Specification 1.01, 2.0, 3.01) iSDIO, SDIO (SDIO Specification 1.1) MMC (MMC Specification 4.1)
Output Interface 32-bit CardBus Type II PC Card Supporting Card SDHC 4GB to 32GB above, SDXC 48GB above. SD 8MB~2GB
Adapter reruired for the followings, miniSD, micro SD/SDHC/SDXC, MMC, MMC plus
Safety Approval CE / FCC
Dimensions 85.0 mm(L)* 54.0 mm(W)* 5.0 mm(H)
